W48-23L2-DPL2
WTM 4500 MB operating at 80 GHz & 23 GHz, supporting 10GHz (mmw), 1200/1232MHz (mw) transmit-receive split.
This model supports full Multi-Band operation with dual rectangular waveguide connections. For 80GHz, it operates TX low and transmitter frequency can une across 71000-76000 MHz.
Use with Aviat's proprietary low-profile Multi-Band antennas
Recommended Partner model is W48-23H2-DPH2.
- Innovative single-box E-band and Microwave solution to support high-reliability 10Gbit/s connections
- 4+0 MB-XD solution comprises E-Band XPIC and Microwave XPIC for long-distance 10Gbit/s multi-band connections
- Layer-1 Link Aggregation for seamless transparent traffic management
- Unique direct-mount antenna solutions makes installation simple and easy
- Supports complex CE and MPLS functionality improving service deployment and management
Highlights
- Full E-band and Microwave solution, with 11-80, 13-80, 15-80, 18-80 and 23-80 options
- QPSK to 256 modulation, with 1/4QPSK and 1/2QPSK support for higher-system gain
- Supports up to 10Gbit/s (licensed PAYG), or 20Gbit/s with MB-XD
- 2x GE electrical and 2x SFP+ supporting 1/ 2.5/ 10 Gbit/s interface
- Full CE and MPLS functionality
- Management options include ProVision+ (native Netconf), Provision (SNMP)
- Upgraded PSU design supporting 24-48v operation, improved surge suppression and IEEE 802.3bt-compliant PoE operation
| Frequency Band | 80/23 GHz |
|---|---|
| Radio Family Type | WTM 4800 |
| Matching Radio SKU | W48-23H2-DPH2 |
| Brand | Aviat Networks |
| Sub Band | 02 |
| TxMin | 71000 |
| TxMax | 76000 |
| Polarity | Single Pol |
| Power Type | POE/DC |
