W42-L6H2-DCX

WTM 4200, L6 GHz OMT, T-R 240/252.04/266MHz, 6295-6420 TX high, +/-40 to +/-57V

WTM 4200 operating at 6 GHz, supporting 40/252.04/266MHz transmit-receive split.

This model has integrated OMT allowing dual polarity operation, and has a circular waveguide output. It operates as TX high and transmitter frequency can tune across 6295-6420 MHz.

Use with direct-mount circular-feed antennas

Recommended Partner model is W42-L6L2-DCX.



 Product Family

  • Dual transceiver fully integrated all-outdoor radio, supporting two radio channels in single or dual polarity.
  • No mediation box required! Use with circular feed direct mount antenna for the simplest 2+0 XPIC solution
  • Dual-polarity has integrated OMT providing single circular waveguide for direct-mount to standard WTM antenna
  • Single-polarity has integrated coupler and can be direct-mounted or remote-mounted or used with external OMT for 4+0 XPIC
  • 4x4 MIMO is a standard configuration supported by WTM 4200 (OMT version)
  • Supports complex CE and MPLS functionality improving service deployment and management



Highlights

  • Covers 5 to 42 GHz solutions, and from 28 to 112MHz channel sizes
  • QPSK to 4096 QAM modulation
  • Supports up to 2.5Gbit/s (licensed PAYG)
  • 2x GE electrical and 2x SFP+ supporting 1/ 2.5/ 10 Gbit/s interface
  • Full CE and MPLS functionality
  • Management options include ProVision+ (native Netconf), Provision (SNMP)
Specifications
Frequency Band L6 GHz
Radio Family Type WTM 4200
Matching Radio SKU W42-L6L2-DCX
Brand Aviat Networks
Unit Height (Packed) 18.8
Unit Length (Packed) 42
Unit Width (Packed) 36
Weight UOM Code KG
Sub Band 02
TxMin 6295
TxMax 6420
Polarity Dual Pol
Power Type DC Only

Each equipment, services and software purchased from Aviat Networks carries with it a commitment of excellence backed by Aviat Networks’ industry-leading warranty policy. All Aviat Networks warranties apply to the Customer or Original Owner also referred to as the end user.


“Final Acceptance” means testing of the Equipment following installation by Aviat Networks at Customer’s site(s) under the terms set forth in the Statement of Work and may be performed on a link by link basis, or when live traffic is cut over, or when the Customer has beneficial use of the Equipment, whichever occurs first. The following table provides the coverage duration for the types of warranties applicable. Please refer to your product ordering guide for the applicable warranty policy for that equipment, service or software.

EQUIPMENT/SERVICES/SOFTWARE WARRANTY
Aviat Networks Equipment Standard
Hardware Warranty – U.S.A, Canada and the Caribbean
24 months from ship date.
Aviat Networks Equipment Standard
Hardware Warranty – Rest of the World
15 months from ship date.
Non-Aviat Networks OEM Equipment
OEM warranty is a pass-through from Aviat Networks from the ship date; maximum OEM warranty.

Lead Time: Quantity ()
